Mk3C Spring Charts
Use this chart to identify the correct spring by door size and style. Click the PN number to go straight to the product.
How to use:
- Click a section title to expand or collapse. Multiple sections can be open at once.
- On mobile, swipe sideways to view all columns. Headers and the first column stay visible.
- Click any PN code to open the product with the option pre-selected.
- On the product page you will see a popup confirming the selection. Click Continue and add to cart.
STEEL DOORS
| Door size (W × H) |  Georgian/Elite |  Beaumont/Elite |  Cathedral/Elite |  Carlton/Elite |  Salisbury/Elite |  Horizon/Elite |
|---|---|---|---|---|---|---|
| 6'6" × 6'3" | - | - | - | PN58 | - | PN58 |
| 6'6" × 6'6" | PN167 | - | - | PN58 | - | PN58 |
| 6'6" × 7'0" | PN167 | - | - | PN58 | - | PN58 |
| 7'0" × 6'3" | - | - | - | N/A | - | - |
| 7'0" × 6'6" | PN57/1 | PN55/2 | PN55/2 | PN58 | PN55/2 | PN58 |
| 7'0" × 7'0" | PN150 | PN155 | PN155 | PN55/2 | PN155 | PN57/1 |
| 7'3½" × 6'4" | - | - | - | PN57/1 | - | PN56/1 |
| 7'5" × 6'3" | - | - | - | - | - | N/A |
| 7'5" × 6'6" | PN55/2 | PN55/2 | PN55/2 | PN57/1 | PN155 | PN56/1 |
| 7'5" × 7'0" | PN108 | - | - | PN150 | PN108 | PN55/2 |
| 7'6" × 6'6" | PN55/2 | - | - | PN57/1 | PN155 | PN57/1 |
| 7'6" × 7'0" | N/A | PN155 | PN155 | N/A | N/A | N/A |
| 7'8½" × 6'3" | - | - | - | N/A | - | N/A |
| 7'8½" × 6'6" | PN150 | - | - | PN55/2 | - | PN155 |
| 7'8½" × 7'0" | N/A | - | - | PN155 | - | PN55/2 |
| 8'0" × 6'3" | - | - | - | N/A | - | N/A |
| 8'0" × 6'6" | PN150 | - | - | PN55/2 | PN150 | PN115 |
| 8'0" × 7'0" | PN108 | - | - | PN155 | PN155 | PN150 |
| 8'2½" × 6'3" | - | - | - | N/A | - | N/A |
| 8'2½" × 6'6" | - | - | - | PN150 | - | PN55/2 |
| 8'2½" × 7'0" | - | - | - | PN155 | - | PN155 |
FIBRE GLASS DOORS
| Door size (W × H) |  Stamford | Arden (White) | Kenmore (Brown) |  Derwent |  Swinton |  Clifton |  Oakham |  Woburn | Wentwood |  Sherwood |
|---|---|---|---|---|---|---|---|---|---|---|
| 7'0" × 6'6" | N/A | PN55/2 | PN55/2 | N/A | PN55/2 | PN55/2 | PN55/2 | N/A | PN155 | PN155 |
| 7'0" × 7'0" | N/A | PN55/2 | PN55/2 | N/A | PN55/2 | PN55/2 | PN55/2 | N/A | PN155 | PN155 |
| 7'5" × 6'6" | N/A | PN155 | PN155 | N/A | PN155 | PN155 | PN155 | N/A | PN55/2 | PN55/2 |
| 7'5" × 7'0" | N/A | PN155 | PN155 | N/A | PN155 | PN155 | PN155 | N/A | PN155 | PN155 |
TIMBER DOORS
| Door size (W × H) | Chevron Cedar |  Vertical Cedar |  Sandhurst |  Cavendish |  Wolsey |  Seymour |  Tudor |  Horizontal Cedar |
|---|---|---|---|---|---|---|---|---|
| 7'0" × 6'6" | PN57/1 | PN57/1 | - | - | PN55/2 | PN55/2 | PN55/2 | PN57/1 |
| 7'0" × 7'0" | PN55/2 | PN55/2 | PN55/2 | PN55/2 | PN155 | PN155 | PN155 | PN55/2 |
| 7'5" × 6'6" | PN55/2 | PN57/1 | PN55/2 | PN55/2 | PN55/2 | PN55/2 | PN55/2 | PN57/1 |
| 7'5" × 7'0" | PN55/2 | PN150 | PN55/2 | PN55/2 | PN155 | PN155 | PN155 | PN150 |
| 7'6" × 6'6" | PN55/2 | PN55/2 | PN55/2 | PN55/2 | PN55/2 | PN55/2 | PN55/2 | - |
| 7'6" × 7'0" | - | PN55/2 | - | - | PN55/2 | PN55/2 | PN55/2 | - |
